1060 Brushed ESC 60A 2-3S LiPo Waterproof Electric Speed Controller

60A Brushed ESC 2-3S LiPo Waterproof Electric Speed Controller for RC 1/16 - 1/10th Touring Cars Buggies Trucks Rock Crawlers

Description: - 3 model( Forward/Brake/Reverse running mode) fits for various vehicles. - High efficiency design, light weight, reliable and very affordable.quality Water-proof and dust-proof,suitable for different Situations. - Compact size, suitable for various car chassis. - Easy to set and easy to use the ESC parameters with jumpers and automatic throttle range calibration. - Great current endurance capability and Great built-in BEC output capacity. Specification: - Small size with built-in capacitor module. - Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection. - Excellent operating feelings and plentiful adjustment options, suitable for most kinds of competitions. - (Fwd =Forward, Br=Brake, Rev=Reverse) - Fwd. Cont. / Peak Current: 60A /360A - Rev. Cont. / Peak Current: 30A /180A - Voltage Range: 2-3S Lipo or 5-9 NiMH - Cars Applicable: 1/10: Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank - Motor Limit: - 2S Lipo or 6 NiMH - 540 or 550 Size Motor: ≥12T Or RPM<30000 @7.2V - 3S Lipo or 9 NiMH - 540 or 550 Size Motor: ≥18T Or RPM< 20000 @7.2V - 4S Lipo or 12 NiMH - Not Available - Resistance: Fwd 0.001Ω, Rev 0.002Ω - BEC Output: 2A/5V (Linear Mode) - PWM Frequency: 1KHz - Running Modes: Forward/Reverse/Brake, Forward/Brake, Forward/Reverse - Net Weight: 36g Size Chart: Size:34x28x22mm/1.3x1.1x0.9inch Package Includes: 1 piece ESC Note: Current and Voltage should perfectly match the machine,over the Peak will make damage to your machine
